Initiate a storage account failover

If the primary endpoint for your geo-redundant storage account becomes unavailable for any reason, you can initiate an account failover. An account failover updates the secondary endpoint to become the primary endpoint for your storage account. Once the failover is complete, clients can begin writing to the new primary region. Forced failover enables you to maintain high availability for your applications.

This article shows how to initiate an account failover for your storage account using the Azure portal, PowerShell, or Azure CLI. To learn more about account failover, see Disaster recovery and storage account failover.

Warning

An account failover typically results in some data loss. To understand the implications of an account failover and to prepare for data loss, review Data loss and inconsistencies.

Note

We recommend that you use the Azure Az PowerShell module to interact with Azure. See Install Azure PowerShell to get started. To learn how to migrate to the Az PowerShell module, see Migrate Azure PowerShell from AzureRM to Az.

Prerequisites

Before you can perform an account failover on your storage account, make sure that:

  • Your storage account is configured for geo-replication (GRS, GZRS, RA-GRS or RA-GZRS). For more information about Azure Storage redundancy, see Azure Storage redundancy.
  • The type of your storage account supports customer-initiated failover. See Supported storage account types.
  • Your storage account doesn't have any features or services enabled that are not supported for account failover. See Unsupported features and services for a detailed list.

Initiate the failover

You can initiate an account failover from the Azure portal, PowerShell, or the Azure CLI.

Note

We recommend that you use the Azure Az PowerShell module to interact with Azure. See Install Azure PowerShell to get started. To learn how to migrate to the Az PowerShell module, see Migrate Azure PowerShell from AzureRM to Az.

To initiate an account failover from the Azure portal, follow these steps:

  1. Navigate to your storage account.

  2. Under Settings, select Geo-replication. The following image shows the geo-replication and failover status of a storage account.

    Screenshot showing geo-replication and failover status

  3. Verify that your storage account is configured for geo-redundant storage (GRS) or read-access geo-redundant storage (RA-GRS). If it's not, then select Configuration under Settings to update your account to be geo-redundant.

  4. The Last Sync Time property indicates how far the secondary is behind from the primary. Last Sync Time provides an estimate of the extent of data loss that you will experience after the failover is completed. For more information about checking the Last Sync Time property, see Check the Last Sync Time property for a storage account.

  5. Select Prepare for failover.

  6. Review the confirmation dialog. When you are ready, enter Yes to confirm and initiate the failover.

    Screenshot showing confirmation dialog for an account failover

Important implications of account failover

When you initiate an account failover for your storage account, the DNS records for the secondary endpoint are updated so that the secondary endpoint becomes the primary endpoint. Make sure that you understand the potential impact to your storage account before you initiate a failover.

To estimate the extent of likely data loss before you initiate a failover, check the Last Sync Time property. For more information about checking the Last Sync Time property, see Check the Last Sync Time property for a storage account.

The time it takes to failover after initiation can vary though typically less than one hour.

After the failover, your storage account type is automatically converted to locally redundant storage (LRS) in the new primary region. You can re-enable geo-redundant storage (GRS) or read-access geo-redundant storage (RA-GRS) for the account. Note that converting from LRS to GRS or RA-GRS incurs an additional cost. The cost is due to the network egress charges to re-replicate the data to the new secondary region. For additional information, see Bandwidth Pricing Details.

After you re-enable GRS for your storage account, Azure begins replicating the data in your account to the new secondary region. Replication time depends on many factors, which include:

  • The number and size of the objects in the storage account. Many small objects can take longer than fewer and larger objects.
  • The available resources for background replication, such as CPU, memory, disk, and WAN capacity. Live traffic takes priority over geo replication.
  • If using Blob storage, the number of snapshots per blob.
  • If using Table storage, the data partitioning strategy. The replication process can't scale beyond the number of partition keys that you use.
