Hybrid Identity Required Ports and Protocols
The following document is a technical reference on the required ports and protocols for implementing a hybrid identity solution. Use the following illustration and refer to the corresponding table.
Table 1 - Microsoft Entra Connect and On-premises AD
This table describes the ports and protocols that are required for communication between the Microsoft Entra Connect server and on-premises AD.
Protocol | Ports | Description |
---|---|---|
DNS | 53 (TCP/UDP) | DNS lookups on the destination forest. |
Kerberos | 88 (TCP/UDP) | Kerberos authentication to the AD forest. |
MS-RPC | 135 (TCP) | Used during the initial configuration of the Microsoft Entra Connect wizard when it binds to the AD forest, and also during Password synchronization. |
LDAP | 389 (TCP/UDP) | Used for data import from AD. Data is encrypted with Kerberos Sign & Seal. |
SMB | 445 (TCP) | Used by Seamless SSO to create a computer account in the AD forest and during password writeback. For more information, see Change a user account's password. |
LDAP/SSL | 636 (TCP/UDP) | Used for data import from AD. The data transfer is signed and encrypted. Only used if you are using TLS. |
RPC | 49152- 65535 (Random high RPC Port) (TCP) | Used during the initial configuration of Microsoft Entra Connect when it binds to the AD forests, and during Password synchronization. If the dynamic port has been changed, you need to open that port. See KB929851, KB832017, and KB224196 for more information. |
WinRM | 5985 (TCP) | Only used if you are installing AD FS with gMSA by Microsoft Entra Connect Wizard |
AD DS Web Services | 9389 (TCP) | Only used if you are installing AD FS with gMSA by Microsoft Entra Connect Wizard |
Global Catalog | 3268 (TCP) | Used by Seamless SSO to query the global catalog in the forest before creating a computer account in the domain. |
Table 2 - Microsoft Entra Connect and Microsoft Entra ID
This table describes the ports and protocols that are required for communication between the Microsoft Entra Connect server and Microsoft Entra ID.
Protocol | Ports | Description |
---|---|---|
HTTP | 80 (TCP) | Used to download CRLs (Certificate Revocation Lists) to verify TLS/SSL certificates. |
HTTPS | 443 (TCP) | Used to synchronize with Microsoft Entra ID. |
For a list of URLs and IP addresses you need to open in your firewall, see Office 365 URLs and IP address ranges and Troubleshooting Microsoft Entra Connect connectivity.
Table 3 - Microsoft Entra Connect and AD FS Federation Servers/WAP
This table describes the ports and protocols that are required for communication between the Microsoft Entra Connect server and AD FS Federation/WAP servers.
Protocol | Ports | Description |
---|---|---|
HTTP | 80 (TCP) | Used to download CRLs (Certificate Revocation Lists) to verify TLS/SSL certificates. |
HTTPS | 443 (TCP) | Used to synchronize with Microsoft Entra ID. |
WinRM | 5985 | WinRM Listener |
Table 4 - WAP and Federation Servers
This table describes the ports and protocols that are required for communication between the Federation servers and WAP servers.
Protocol | Ports | Description |
---|---|---|
HTTPS | 443 (TCP) | Used for authentication. |
Table 5 - WAP and Users
This table describes the ports and protocols that are required for communication between users and the WAP servers.
Protocol | Ports | Description |
---|---|---|
HTTPS | 443 (TCP) | Used for device authentication. |
TCP | 49443 (TCP) | Used for certificate authentication. |
