Create an incremental snapshot for managed disks

Article
09/02/2024

Applies to: ✔️ Linux VMs ✔️ Windows VMs ✔️ Flexible scale sets ✔️ Uniform scale sets

Incremental snapshots are point-in-time backups for managed disks that, when taken, consist only of the changes since the last snapshot. The first incremental snapshot is a full copy of the disk. The subsequent incremental snapshots occupy only delta changes to disks since the last snapshot. When you restore a disk from an incremental snapshot, the system reconstructs the full disk that represents the point in time backup of the disk when the incremental snapshot was taken. This capability for managed disk snapshots potentially allows them to be more cost-effective, since, unless you choose to, you don't have to store the entire disk with each individual snapshot. Just like full snapshots, incremental snapshots can be used to either create a full managed disk or a full snapshot. Both full snapshots and incremental snapshots can be used immediately after being taken. In other words, once you take either snapshot, you can immediately read the underlying data and use it to restore disks.

There are a few differences between an incremental snapshot and a full snapshot. Incremental snapshots will always use standard HDD storage, irrespective of the storage type of the disk, whereas full snapshots can use premium SSDs. If you're using full snapshots on Premium Storage to scale up VM deployments, we recommend you use custom images on standard storage in the Azure Compute Gallery. It will help you achieve a more massive scale with lower cost. Additionally, incremental snapshots potentially offer better reliability with zone-redundant storage (ZRS). If ZRS is available in the selected region, an incremental snapshot will use ZRS automatically. If ZRS isn't available in the region, then the snapshot will default to locally redundant storage (LRS). You can override this behavior and select one manually but, we don't recommend that.

Incremental snapshots are billed for the used size only. You can find the used size of your snapshots by looking at the Azure usage report. For example, if the used data size of a snapshot is 10 GiB, the daily usage report will show 10 GiB/(31 days) = 0.3226 as the consumed quantity.

Restrictions

Incremental snapshots currently can't be moved between subscriptions.
You can currently only generate SAS URIs of up to five snapshots of a particular snapshot family at any given time.
You can't create an incremental snapshot for a particular disk outside of that disk's subscription.
Incremental snapshots can't be moved to another resource group. But, they can be copied to another resource group or region.
Up to seven incremental snapshots per disk can be created every five minutes.
A total of 500 incremental snapshots can be created for a single disk. The 500 quota limit is not over the lifetime of a disk, but at any given point in time. You can always delete older snapshots of a disk to make room for newer snapshots.
You can't get the changes between snapshots taken before and after you changed the size of the parent disk across 4-TB boundary. For example, You took an incremental snapshot snapshot-a when the size of a disk was 2 TB. Now you increased the size of the disk to 6 TB and then took another incremental snapshot snapshot-b. You can't get the changes between snapshot-a and snapshot-b. You have to download the full copy of snapshot-b created after the resize. Subsequently, you can get the changes between snapshot-b and snapshots created after snapshot-b.
When you create a managed disk from a snapshot, it starts a background copy process. You can attach a disk to a VM while this process is running but you'll experience performance impact. You can use CompletionPercent property to check the status of the background copy for Ultra Disks and Premium SSD v2 disks.

Create incremental snapshots

You can use the Azure CLI to create an incremental snapshot. You need the latest version of the Azure CLI. See the following articles to learn how to either install or update the Azure CLI.

The following script creates an incremental snapshot of a particular disk:

# Declare variables
diskName="yourDiskNameHere"
resourceGroupName="yourResourceGroupNameHere"
snapshotName="desiredSnapshotNameHere"

# Get the disk you need to backup
yourDiskID=$(az disk show -n $diskName -g $resourceGroupName --query "id" --output tsv)

# Create the snapshot
az snapshot create -g $resourceGroupName -n $snapshotName --source $yourDiskID --incremental true

You can identify incremental snapshots from the same disk with the SourceResourceId property of snapshots. SourceResourceId is the Azure Resource Manager resource ID of the parent disk.

You can use SourceResourceId to create a list of all snapshots associated with a particular disk. Replace yourResourceGroupNameHere with your value and then you can use the following example to list your existing incremental snapshots:

# Declare variables and create snapshot list
subscriptionId="yourSubscriptionId"
resourceGroupName="yourResourceGroupNameHere"
diskName="yourDiskNameHere"

az account set --subscription $subscriptionId

diskId=$(az disk show -n $diskName -g $resourceGroupName --query [id] -o tsv)

az snapshot list --query "[?creationData.sourceResourceId=='$diskId' && incremental]" -g $resourceGroupName --output table

You can use the Azure PowerShell module to create an incremental snapshot. You need the latest version of the Azure PowerShell module. The following command will either install it or update your existing installation to latest:

Install-Module -Name Az -AllowClobber -Scope CurrentUser

Once that is installed, sign in to your PowerShell session with Connect-AzAccount -Environment AzureChinaCloud.

To create an incremental snapshot with Azure PowerShell, set the configuration with New-AzSnapShotConfig with the -Incremental parameter and then pass that as a variable to New-AzSnapshot through the -Snapshot parameter.

$diskName = "yourDiskNameHere"
$resourceGroupName = "yourResourceGroupNameHere"
$snapshotName = "yourDesiredSnapshotNameHere"

# Get the disk that you need to backup by creating an incremental snapshot
$yourDisk = Get-AzDisk -DiskName $diskName -ResourceGroupName $resourceGroupName

# Create an incremental snapshot by setting the SourceUri property with the value of the Id property of the disk
$snapshotConfig=New-AzSnapshotConfig -SourceUri $yourDisk.Id -Location $yourDisk.Location -CreateOption Copy -Incremental
New-AzSnapshot -ResourceGroupName $resourceGroupName -SnapshotName $snapshotName -Snapshot $snapshotConfig

You can identify incremental snapshots from the same disk with the SourceResourceId and the SourceUniqueId properties of snapshots. SourceResourceId is the Azure Resource Manager resource ID of the parent disk. SourceUniqueId is the value inherited from the UniqueId property of the disk. If you delete a disk and then create a new disk with the same name, the value of the UniqueId property changes.

You can use SourceResourceId and SourceUniqueId to create a list of all snapshots associated with a particular disk. Replace yourResourceGroupNameHere with your value and then you can use the following example to list your existing incremental snapshots:

$resourceGroupName = "yourResourceGroupNameHere"
$snapshots = Get-AzSnapshot -ResourceGroupName $resourceGroupName

$incrementalSnapshots = New-Object System.Collections.ArrayList
foreach ($snapshot in $snapshots)
{

    if($snapshot.Incremental -and $snapshot.CreationData.SourceResourceId -eq $yourDisk.Id -and $snapshot.CreationData.SourceUniqueId -eq $yourDisk.UniqueId){

        $incrementalSnapshots.Add($snapshot)
    }
}

$incrementalSnapshots

You can also use Azure Resource Manager templates to create an incremental snapshot. You'll need to make sure the apiVersion is set to 2022-03-22 and that the incremental property is also set to true. The following snippet is an example of how to create an incremental snapshot with Resource Manager templates:

{
  "$schema": "https://schema.management.azure.com/schemas/2015-01-01/deploymentTemplate.json#",
  "contentVersion": "1.0.0.0",
  "parameters": {
    "diskName": {
      "type": "string",
      "defaultValue": "contosodisk1"
    },
  "diskResourceId": {
    "defaultValue": "<your_managed_disk_resource_ID>",
    "type": "String"
  }
  },
  "resources": [
  {
    "type": "Microsoft.Compute/snapshots",
    "name": "[concat( parameters('diskName'),'_snapshot1')]",
    "location": "[resourceGroup().location]",
    "apiVersion": "2022-03-22",
    "properties": {
      "creationData": {
        "createOption": "Copy",
        "sourceResourceId": "[parameters('diskResourceId')]"
      },
      "incremental": true
    }
  }
  ]
}

Check snapshot status

Incremental snapshots of Ultra Disks can't be used to create new disks until the background process copying the data into the snapshot has completed.

You can use either the CLI or PowerShell sections to check the status of the background copy from a disk to a snapshot.

Important

You can't use the following sections to get the status of the background copy process for disk types other than Ultra Disk. Snapshots of other disk types always report 100%.

CLI

You have two options for getting the status of snapshots. You can either get a list of all incremental snapshots associated with a specific disk, and their respective status, or you can get the status of an individual snapshot.

CLI - List incremental snapshots

The following script returns a list of all snapshots associated with a particular disk. The value of the CompletionPercent property of any snapshot must be 100 before it can be used. Replace yourResourceGroupNameHere, yourSubscriptionId, and yourDiskNameHere with your values then run the script:

# Declare variables and create snapshot list
subscriptionId="yourSubscriptionId"
resourceGroupName="yourResourceGroupNameHere"
diskName="yourDiskNameHere"
az account set --subscription $subscriptionId
diskId=$(az disk show -n $diskName -g $resourceGroupName --query [id] -o tsv)
az snapshot list --query "[?creationData.sourceResourceId=='$diskId' && incremental]" -g $resourceGroupName --output table

CLI - Individual snapshot

You can also check the status of an individual snapshot by checking the CompletionPercent property. Replace $sourceSnapshotName with the name of your snapshot then run the following command. The value of the property must be 100 before you can use the snapshot for restoring disk or generate a SAS URI for downloading the underlying data.

az snapshot show -n $sourceSnapshotName -g $resourceGroupName --query [completionPercent] -o tsv

PowerShell

You have two options for getting the status of snapshots. You can either get a list of all incremental snapshots associated with a particular disk and their respective status, or you can get the status of an individual snapshot.

PowerShell - List incremental snapshots

The following script returns a list of all incremental snapshots associated with a particular disk that haven't completed their background copy. Replace yourResourceGroupNameHere and yourDiskNameHere, then run the script.

$resourceGroupName = "yourResourceGroupNameHere"
$snapshots = Get-AzSnapshot -ResourceGroupName $resourceGroupName
$diskName = "yourDiskNameHere"
$yourDisk = Get-AzDisk -DiskName $diskName -ResourceGroupName $resourceGroupName
$incrementalSnapshots = New-Object System.Collections.ArrayList
foreach ($snapshot in $snapshots)
{
    if($snapshot.Incremental -and $snapshot.CreationData.SourceResourceId -eq $yourDisk.Id -and $snapshot.CreationData.SourceUniqueId -eq $yourDisk.UniqueId)
    {
    $targetSnapshot=Get-AzSnapshot -ResourceGroupName $resourceGroupName -SnapshotName $snapshotName
        {
        if($targetSnapshot.CompletionPercent -lt 100)
            {
            $incrementalSnapshots.Add($targetSnapshot)
            }
        }
    }
}
$incrementalSnapshots

PowerShell - individual snapshots

You can check the CompletionPercent property of an individual snapshot to get its status. Replace yourResourceGroupNameHere and yourSnapshotName then run the script. The value of the property must be 100 before you can use the snapshot for restoring disk or generate a SAS URI for downloading the underlying data.

$resourceGroupName = "yourResourceGroupNameHere"
$snapshotName = "yourSnapshotName"
$targetSnapshot=Get-AzSnapshot -ResourceGroupName $resourceGroupName -SnapshotName $snapshotName
$targetSnapshot.CompletionPercent

Check sector size

Snapshots with a 4096 logical sector size can only be used to create Ultra Disks. They can't be used to create other disk types. Snapshots of disks with 4096 logical sector size are stored as VHDX, whereas snapshots of disks with 512 logical sector size are stored as VHD. Snapshots inherit the logical sector size from the parent disk.

To determine whether or your Ultra Disk snapshot is a VHDX or a VHD, get the LogicalSectorSize property of the snapshot.

The following command displays the logical sector size of a snapshot:

az snapshot show -g resourcegroupname -n snapshotname --query [creationData.logicalSectorSize] -o tsv

Next steps

See the following articles to create disks from your snapshots using the Azure CLI or Azure PowerShell module.

See Copy an incremental snapshot to a new region to learn how to copy an incremental snapshot across regions.

If you have more questions on snapshots, see the snapshots section of the FAQ.

If you'd like to see sample code demonstrating the differential capability of incremental snapshots, using .NET, see Copy Azure Managed Disks backups to another region with differential capability of incremental snapshots.
